[Translate to 中文:] PLS-PP Level Sensors
[Translate to 中文:]
Our PLS-PP Level Sensors are available as a standard with 20 mm, 31 mm, 41 mm, and 51 mm stem lenght - individual variants with different dimensions or more than one switching point are produces sepecifically according to your needs! These Level Sensors comply with FDA and NSF regulations and are suitable for food contact.
优势比较
尺寸:| PLS-020A-3PPI | PLS-020B-3PPI | PLS-031A-3PPI | PLS-031A-6PPI | PLS-031B-3PPI | PLS-031B-6PPI | PLS-041A-3PPI | PLS-041A-6PPI | PLS-041B-3PPI | PLS-041B-6PPI | PLS-051A-3PPI | PLS-051A-6PPI | PLS-051B-3PPI | PLS-051B-6PPI | ||
| 总长 | mm | 29.5 | 29.5 | 43.0 | 43.0 | 43.0 | 43.0 | 53.0 | 53.0 | 53.0 | 53.0 | 51.0 | 51.0 | 51.0 | 51.0 |
| PLS-020A-3PPI | PLS-020B-3PPI | PLS-031A-3PPI | PLS-031A-6PPI | PLS-031B-3PPI | PLS-031B-6PPI | PLS-041A-3PPI | PLS-041A-6PPI | PLS-041B-3PPI | PLS-041B-6PPI | PLS-051A-3PPI | PLS-051A-6PPI | PLS-051B-3PPI | PLS-051B-6PPI | ||
| 接触方式 | A | B | A | A | B | B | A | A | B | B | A | A | B | B | |
| 最大接触功率 | W/VA | 10 | 10 | 10 | 50 | 10 | 50 | 10 | 50 | 10 | 50 | 10 | 50 | 10 | 50 |
| 最大开关电流 | A | 0.7 | 0.7 | 1 | 1.5 | 1 | 1.5 | 1 | 1.5 | 1 | 1.5 | 0.5 | 1.5 | 0.5 | 1.5 |
| 最大开关电压(直流) | VDC | 180 | 180 | 200 | 200 | 200 | 200 | 200 | 200 | 200 | 200 | 200 | 200 | 200 | 200 |
| 最大开关电压(交流) | VAC | 130 | 130 | 140 | 250 | 140 | 250 | 140 | 250 | 140 | 250 | 140 | 250 | 140 | 250 |
| 工作温度 | °C | -20 到 +80 | -20 到 +80 | -20 到 +80 | -20 到 +80 | -20 到 +80 | -20 到 +80 | -20 到 +80 | -20 到 +80 | -20 到 +80 | -20 到 +80 | -20 到 +80 | -20 到 +80 | -20 到 +80 | -20 到 +80 |
| 外壳材质 | PP | PP | PP | PP | PP | PP | PP | PP | PP | PP | PP | PP | PP | PP | |
| 电线型号 | UL 1007, AWG 24 | UL 1007, AWG 24 | UL 1007, AWG 24 | UL 1007, AWG 22 | UL 1007, AWG 24 | UL 1007, AWG 22 | UL 1007, AWG 24 | UL 1007, AWG 22 | UL 1007, AWG 24 | UL 1007, AWG 22 | UL 1007, AWG 24 | UL 1007, AWG 22 | UL 1007, AWG 24 | UL 1007, AWG 22 |
[Translate to 中文:] PLS-PP-Level Sensor advantages
[Translate to 中文:]
- Polypropylene-Housing
- Mains voltage and Normally Closed versions available
- Suitable for food contact
- FDA and NSF compliant
- Cutomized solutions on request
